BD6-2234-2020
V12 combination unit
A V12 combination unit with an ABS housing and IP44 rating. The catalogue lists two 32 A, 3P+E+N sockets and two 16 A, 2P+E sockets. V12 denotes a fuse capacity of 12.
IP ratingIP44
Request a quote ↗BD6-2234-2020
Technical specifications
- Product code
- BD6-2234-2020
- Barcode
- 8698523905982
- IP rating
- IP44
- Material
- ABS
- Socket option
- with sockets
- Weight (g)
- 1747
- Box quantity
- 1
- Carton quantity
- 6
Technical drawing
Product overview
BD6-2234-2020A V12 combination unit with an ABS housing and IP44 rating. The catalogue lists two 32 A, 3P+E+N sockets and two 16 A, 2P+E sockets. V12 denotes a fuse capacity of 12.
Applications
Bringing three-phase and single-phase outlets together in one distribution enclosure. Select the unit by outlet configuration as well as fuse capacity.
Questions about this product
Before you order
Confirm wiring, protective devices and the required supply with our team. V12 describes fuse capacity; it does not by itself confirm that fuses or internal wiring are included.
How do I request a quotation?
Add this product to your quote list, enter the quantity and send your request. Our export team will review the product code and destination market.
Request a quote →Product documents
These are product-family documents. Check the model and scope listed in each document.
